Peru 200 m3/hour 440v 60hz 90kw SS316L Sea Water Submersible Pump Lifitng
Peru customer, working in Peru Drilling International Ltd. was looking for Caudal : 200 m3/h; cabeza: 110 m; potencia: 90kw, 440vv, 60HZ material de acero inoxidable.
He need also the pump to come with 100 meters of cable with the technical sheet of the cable. The pump outlet size has to be 6 inches, With everything and the cooling tube when wemeasure our pump you can send me the photo of our pump with the measurements.
According to his pump specifications, we chose sea water submersible pump as below:
| Model | 300QJH200-100-90kw |
| Flow rate | 300m3/hr |
| Head meters | 100 m |
| Motor power | 90kw 120hp |
| Power supply | 3phase 440v 60hz |
| Out let dia | 150mm |
| Pump material | SS316L |
| Impeller | Duplex stainless steel |
| Pump shaft | Duplex stainless steel |
| Cables | Including 60m 3*10m EPR insulated shipboard power cables without joints. |
Kindly note:
1. Motor cavity MUST BE fill with clean water before the pump testing, installation and during working;
2. DO NOT use the cable as sling when install, should wear ropes on the handle;
3. The first stage impeller should go down the water level;
4. After shut down the power, should wait for more than 3mins when restart the pump;
5. When the pump finish work, it’s better to cut off the power.
200m3/hr water submersible pump models:
(Notice:flow rate, head meters, power supply, material, ODM OEM is available)
| Model | Power | Flow | Head | Outlet Diameter |
| QJ type | kw | hp | m3/h | m | Inch (") |
| 300QJ200-20/1 | 18.5 | 25 | 186-214 | 17-23 | 6" |
| 300QJ200-30/1 | 25 | 35 | 186-214 | 27-33 | 6" |
| 300QJ200-40/2 | 37 | 50 | 186-214 | 35-45 | 6" |
| 300QJ200-60/3 | 55 | 75 | 186-214 | 51-69 | 6" |
| 300QJ200-80/4 | 75 | 100 | 186-214 | 68-92 | 6" |
| 300QJ200-100/5 | 90 | 120 | 186-214 | 85-115 | 6" |
| 300QJ200-120/6 | 110 | 150 | 186-214 | 100-138 | 6" |
Why choose Zhengzhou Shenlong Pump Industry CO.,Ltd?
1. Specialized production Manufacturer for Submersible Pump
2. Focus on technological innovation, Over Industry leading level
3. Good experience at Domestic and oversea market
4. Carefully paint for Good appearance
5. Years of International service standards, Engineer one-to-one service
6. CE; ISO; ABS
FAQ
Q:How long is warranty?
A:About 24 months.
Q:How long is production lead time?
A:Depends on quantity, the normal small amount production is about 10-25 days.
Q:What’s type of shipping?
A:Usually by sea, and will be based on the customer's destination to choose the most favorable most appropriate way
Q:What is the shipping terms you can provide?
A:Depends on customer's requirements, we can provide different transportation terms,
such as EXW, FOB, CIF.
Q:How can I pay for my items? What is the payment you can provide?
A:Usually by T/T, 50% down payment once PI confirmed, the balance will be paid after inspection and before shipment. L/C at sight.
Product Tags:
|
|
200M3/Hour 100M SS316L Sea Water Submersible Pump For Offshore Facility Images
|
